An evident shear plane observed at the end of a CIUc triaxial test

🔍 An evident shear plane observed at the end of a CIUc triaxial test on a firm clay sample. Pore water pressure were measured at both mid-height and base pedestal, and the test was continued to a large strain beyond failure as per the client’s request.

At Geolabs Limited, we operate over 60 standard effective stress triaxial and 8 fully instrumented advanced triaxial systems, enabling high-capacity testing while ensuring highest-quality results. ✅🔬
